SB-8h SLEW BOOM – Horticulture Series – Hydralada
SB-8h SLEW BOOM – Horticulture Series – Hydralada
Great reach and self levelling
The SB-8h SLEW BOOM machine allows you to reach places you’ve never reached before. Dynamic self levelling maintains the chassis to within four degrees while working on slopes of up to 20 degrees. The slew articulated boom adds to the machine’s versatility and the powerful diesel powered hydraulic four wheel drive makes this a truly all terrain platform.
Automatic Self Levelling
Inbuilt safety system
Inbuilt, state-of-the-art safety system automatically levels the chassis and monitors slopes for optimum stability when operating on steep terrain.
Slew Articulated Boom
340 degree slew with articulated boom
Boom turns on a turret with no need to move the chassis for access. Increases working area and allows machine to reach otherwise unobtainable places.
Four Wheel Drive
Traction and stability
Powered by a 45hp diesel engine, the smooth hydrostatic four wheel drive will manoeuvre over humps and hollows, and climb steep hills.
Picking Bag
Bag quick taches to front of operator platform and is designed to handle fruit without bruising. Fruit passes through three compartments then empties into field bin. Trials show it has the best results, delivering high quality fruit to the pack house.
Platform Padding Surround
For optimum operator comfort, the Platform Padding Surround is a closed cell foam body support fitted around the top rail.
Platform Cover
Weather proof PVC platform cover which fits over the platform and picking bag attachment to protect the machine’s controls.
Additional information
| Lift Height To Platform | 8.00m |
|---|---|
| Engine | 45hp Water Cooled 4 Cylinder Diesel Engine |
| Maximum Platform Rated Capacity | 175kg |
| Drive Train And Wheels | 4 X Powerful Planetry Wheel Drives, Hydrostatic Proportional Control, Heavy Duty Wheel Equipment, Automatic Braking System |
| Chassis Construction | Heavy Duty Chassis Construction, Articulated Twin Boom, Solid Steel Frame, Steel Bonnets, Fully Protected Hydraulic Hosing |
| Controls | Joystick Drive Control With Power Steering, Foot Control For All Boom Functions Including Slew, Dual Control For Boom Functions Located At Base, Emergency Stop Buttons |
