Rhino Epic 4150 Side-Throw Flex-Wing Orchard Slasher

Rhino Epic 4150 Side-Throw Flex-Wing Orchard Slasher

Everything we love about the 4150 series, with SideThrow!

The Rhino 4150 “Epic” series rotary cutters are a beast in the field easily handling brush up to 4” in diameter! Now with the side throw variant this slasher is a great option for maintaining orchards, directing the grass clippings easily and efficiently under the tree line. Many orchardists have proved that depositing grass clippings under the trees aids in moisture retention and establishment of good bacteria. This in turn can help in the health of the trees and thus increase the yield.

Other Suitable applications are clearing brush up to 100mm in diameter, Farm Use, Heavy-duty agricultural use, Pasture Maintenance.

Name(Required)
Address(Required)
This field is for validation purposes and should be left unchanged.

Thanks for downloading

Before your download begins, please fill out the form below.

2019 Rhino Epic 4150 Flex-wing SideThrow Slasher – Built For Orchards

Everything we love about the 4150 series, with Side discharge!

The Rhino 4000 “Epic” series rotary cutters are a beast in the field easily handling brush up to 4” in diameter! Now with the sidethrow slasher variant this is a great option for maintaining orchards. with its ability to direct the grass clippings easily and efficiently under the tree line. Many orchardists have proved that depositing grass clippings under the trees aids in moisture retention and establishment of good bacteria. This in turn can help in the health of the trees and thus increase the yield.

The RH4150SDTR 4150 sidethrow slasher has been designed especially for the avocado & tree crop industry. The effective sidethrow design of this machine is result of many farm visits, trials and listening to growers needs, in particular the team from Sunny Spot Packhouse. Avocado growers were after a robust three point linkage, folding wing sidethrow slasher that would mow a full row in a single pass while discharging the clippings under the avocado trees to retain moisture and establish good bacteria. Furthermore they needed machine the could easily handle any small to medium size prunings they may be hidden in the grass.

4150 Side-Throw Flex-wing Orchard Slasher Features include:

    • 60 Horsepower PTO Requirement
    • 250 Horsepower Gearbox
    • Chain Guard Safety Deflectors
    • Professional Grade Hitch with locking feature
      nallowing for single user attachment
    • “T” brace & gussets increase impact resistance
      nand deck strength
    • 3. 1/2” x 5 “ cross sectional blades designed for
      nextreme cut capacity
    • EZ225 Gearboxes designed and perfected,
      nby RhinoAg Engineers
    • Bolt on, replaceable side skirts made of AR400
      n– basically indestructible
    • Optional, double chain guards – flat formed for
      ndurability
    • HD RhinoTrax tires made of foam and recycled
      nmaterial and put on a 1PC 10MM HD rim for
      nunmatched durability
    • CAT 6 Walterscheid Drive System – 1 zert/ 60
      nhour service interval for increased run time

WARRANTY

    • Industry-leading toughness. Industry-leading warranty.
    • Rhino products are built to take on whatever you can throw at them. But if something should break, you’ll be glad to know our warranties are just as strong. See your local Rhino dealer for complete details.

FULL MACHINE WARRANTY

    • 1 YEAR

GEARBOX WARRANTY

    • 6 YEARS

SEALS WARRANTY

    • 2 YEARS

LIMITED DRIVELINE WARRANTY

    • 2 YEARS

Specifications

Model Working Width Weight HP (Min.) Finish
RH4150SDTR-G 4.5m (15′) 2447 kg 60 Galvanised Deck
RH4150SDTR 4.5m (15′) 2447 kg 60 Painted Deck
