What Size Telehandler Do I Need for a GreenTec Quadsaw & Multi Carrier?

Choosing the right telehandler for your GreenTec Quadsaw setup isn’t just about whether it can lift the attachment off the ground.

It’s about stability at reach, load chart capacity, and safe operating margin.

Telehandlers are typically described by their lifting capacity — for example, a “3.5-tonne machine” refers to a telehandler rated to lift 3,500 kg. However, the machine’s gross weight is just as important, because heavier machines generally provide greater stability when working at height or reach.

Below is a clear breakdown of the correct GreenTec combinations and the recommended telehandler size for each.

Approved GreenTec Combinations

GreenTec Quadsaws must be paired with the correct Multi Carrier model:

• LRS 1402 →  HXF 2303

• LRS 1602 → HXF 2803 or HXF 2803 Tele

• LRS 2002 → HXF 3303 or HXF 3303 Tele

• LRS 2402 → HXF 3303 or HXF 3303 Tele

Mixing outside these combinations is not recommended.

Telehandler Size Guide by Model

LRS 1402 + HXF 2303

Combined attachment weight: approx. 158 kg
(Carrier 110 kg + Saw 48 kg)

Recommended telehandler:

• Minimum lift capacity: 1,500 kg class

• Typical gross machine weight: 2,000–4,000 kg

This is a lightweight setup, suitable for smaller telehandlers. However, stability must still be considered when working at height.

LRS 1602 + HXF 2803 / HXF 2803 Tele

Combined attachment weight:

• Quadsaw LRS 1602 Weight: 110kg
  + Multi-Carrier HXF 2803 Weight : 260 kg
  = Combined attachment weight: approx. 370kg
  Or
• Quadsaw LRS 1602 Weight: 110kg
  + Tele Multi-Carrier HXF 2803 Weight: 285 kg
  = Combined attachment weight: approx. 395kg

Recommended telehandler:

• Minimum lift capacity: 2,500 kg class

• Typical gross machine weight: 4,000–6,000 kg

This setup provides greater reach and leverage. A 2.5-tonne class machine is the practical minimum, with additional weight preferred for stability.

LRS 2002 + HXF 3303 / HXF 3303 Tele

Combined attachment weight:

• Quadsaw LRS 2002 Weight: 198kg
  + Multi-Carrier 3303 HXF Weight :398 kg
  = Combined attachment weight: approx. 596kg
  Or
• Quadsaw LRS 2002 Weight: 198kg
  + Tele Multi-Carrier HXF 3303 Tele Weight:428 kg
  = Combined attachment weight: approx. 626kg

Recommended telehandler:

• Minimum lift capacity: 3,000 kg class

• Typical gross machine weight: 6,000–8,000 kg

At this size, stability becomes critical. A 3.0-tonne machine is generally the minimum.

LRS 2402 + HXF 3303 / HXF 3303 Tele

Combined attachment weight:

• Quadsaw LRS 2402 Weight: 239kg
  + Multi-Carrier HXF 3303 Weight: 439 kg
  = Combined attachment weight: approx. 678kgOr
• Quadsaw LRS 2402 Weight: 239kg
  + Tele Multi-Carrier HXF 3303 Weight:469 kg
  = Combined attachment weight: approx. 708kg

Recommended telehandler:

• Minimum lift capacity: 3,500 kg class

• Typical gross machine weight: 6,500–9,000 kg

This is the largest and most common heavy-duty setup. Although the attachment weight may seem modest, the forward reach significantly increases leverage on the machine. A 4-tonne telehandler is strongly recommended for safe and stable operation.

Why Lift Capacity Alone Isn’t Enough

Even if your attachment weighs under 600kg, it doesn’t mean any Telehandler can lift it as the centre of weight is offset to the boom and telehandlers lose lifting capacity as the boom extends.

You must check:

• The hydraulic flow requirements of the attachment. The machine must have suitable flow when at idle, to guarantee maximum performance at all times.

• Stability when operating on uneven ground and whether counterweights are required.

A machine that is technically capable of lifting the attachment may still feel unstable or operate close to its limits.

Quick Reference Summary

Need Help Matching Your Machine?

If you’re unsure whether your current telehandler is suitable, we can check your exact model and load chart for you.

Simply provide:

• Telehandler make and model

• Maximum lift capacity

• Working height required

• Whether counterweights are fitted

We’ll confirm whether your machine is suitable — or recommend the right class for your operation.

Contact DTE Equipment Australia today to discuss Greentec Quadsaws, Multi Carriers, and telehandler compatibility for your operation.
