Major Cyclone Mower

Major Cyclone Mower

The MAJOR Range of Cyclone Mowers has been designed to do the work of a flail mower but requires a fraction of the power and fuel that a flail mower would consume.nnnnThese machines are strong, rugged and robust; specifically designed for use in set-aside, forestry margin management and sensitive environmental scrubland control. This machine easily copes with the toughest of conditions including shrub, saplings, gorse and brush as well as the clearance of arable stubble, including maize, rapeseed and cotton crops.nnnnStrenx 700 MC high-strength steel is used in the manufacture of these machines. This material is stronger than steel traditionally used in machinery manufacturing. The undersole discs are produced from Hardox 450, a wear and abrasion resistant steel. An optional side shift unit is available which allows the operator adjust the mower 30cm to the left and right.

    • Can be front or rear mounted (to be specified when ordering)
    • Patented ‘blender’ double chop blade system
    • 25% less power and fuel consumption required than a similar sized flail machine
    • Impact shock reducing swinging hardened spring steel blades
    • Low maintenance machine with less wearing parts than a flail mower
    • Heavy duty rear roller
    • Galvanised finish.
Name(Required)
Address(Required)
This field is for validation purposes and should be left unchanged.

Thanks for downloading

Before your download begins, please fill out the form below.

Specifications

Model MJ30-200 MJ30-250 MJ30-280 MJ30-300 MJ30-350 MJ30-420 MJ30-560
Overall width 2.1m (7′) 2.65m (8’9”) 3.00m (10′) 3.0m (10′) 3.65m (12′) 4.43m (14’6”) 5.81m (19′)
Cutting width 2m (6′ 5″) 2.5m (8’1”) 2.80m (9’2”) 2.85m (9′ 4″) 3.5m (11′ 5″) 4.20m (13’9”) 5.60m (18’4”)
Transport Width 2.10m (7′) 2.65m (8’9”) 3.00m (10′) 3.00m (10′) 2.50m (8’2″) 2.50m (8’2”) 2.03m (6’9”)
No. of Blades 12 16 16 12 20 24 32
No. of Rotors 3 4 4 3 5 6 8
Power (HP) 50 – 100 70 – 120 80 – 120 80 – 140 90 -140 100 – 150 110 – 150
PTO (rpm) 540 1000 1000 1000 1000 1000 1000
Blade speed 75m/s ’75m/s ’58m/s ’75m/s ’58m/s ’58m/s ’58m/s
Cutting height 40-200mm 40-200mm 40-200mm 40-200mm 50-170mm 50-170mm 50-170mm
Weight 600kg 785kg 945kg 890kg 1120kg 1265kg 1680kg



Videos

Mowing in Macadamias made easy with a single pass from the 4.2 metre MJ31-420DW Cyclone. The Cyclone follows the V shape between the rows, mulching the grass and leaves making harvesting easy.
